no.6 digital silicon case
power supply: ac220v to plus or minus 10% / 50 1 hz
loop: 6
power: 8 kw/ch
the machine power consumption: min. 25.6 w
digital signal; dmx512
analog signal: dc0 ~ 10 v / 2 ma
the dimming range; 1% - 100%.
trigger accuracy; 256
field; 24
field operation time; 1-99 - s
preheating value; 1% - 9%.
air switch rated current; 40 a
20 kg net
size 483 mm * 470 mm * 178 mm
